Complete Process of Powder Metallurgy: The Logic of Precision Manufacturing from Powder Production to Sintering

In the field of high-end manufacturing, powder metallurgy has become an indispensable core process in automotive, new energy, aerospace, and other industries thanks to its key advantages: precision, efficiency, energy saving, and environmental protection. It breaks through the limitations of the traditional “subtractive machining” model and adopts an additive/near-net-shape logic of “powder forming + high-temperature sintering” to achieve precise replication and mass production of components. Every step in the complete process directly determines the final product’s precision, density, and mechanical properties. Based on the core procedures, this article explains the fundamental logic of precision manufacturing in powder metallurgy, from powder production to sintering.

1. Powder Production: The Foundation of Precision Manufacturing

Powder quality defines the upper limit of performance.

Powder production is the first step of powder metallurgy. Its core is to process metal or alloy raw materials into uniform, pure, and size-controllable powder. The powder quality directly determines the subsequent forming and sintering results.

At present, mainstream powder production methods are divided into physical and chemical methods. Among them, atomization (water atomization, gas atomization) is the most widely used, accounting for more than 70% of industrial powder production.

High-quality powder must meet three core requirements:

- Qualified purity (impurity content below 0.5%)

- Uniform particle size (usually controlled at 10–100 μm)

- Regular morphology (spherical or near-spherical for good flowability)

During production, atomization pressure, cooling rate, and other parameters must be precisely controlled to avoid oxidation and agglomeration, laying a solid foundation for subsequent precision forming.

2. Forming: Shaping the Component

Accurate control of density and dimensional precision.

Forming is the process of converting metal powder into a “green compact” with a preliminary shape and certain strength. The core is uniform feeding and precise pressing, balancing shape complexity and density uniformity. Three mainstream forming technologies are widely used:

- Compaction forming: Suitable for simple-structured parts. Powder is densified via die pressing, with a forming precision of ±0.01 mm.

- Powder injection molding (PIM): Suitable for complex-shaped parts. Powder is mixed with a binder and injected into a mold, solving the difficulty of processing complex structures with traditional processes.

- Isostatic pressing: Applies uniform pressure in all directions, greatly improving green density, ideal for high-end precision components.

3. Sintering: The Core Solidification Step

Activating the mechanical properties of powder metallurgy parts.

Sintering is the core stage of the entire powder metallurgy process. Essentially, the green compact is heated at a high temperature (below the melting point of the raw material) in a controlled atmosphere. Powder particles achieve densification through diffusion, bonding, and recrystallization, finally forming a finished product with stable mechanical properties.

Sintering quality directly determines key indicators such as strength, hardness, and wear resistance.

Three key parameters must be strictly controlled during sintering:

- Sintering temperature (usually 70%–90% of the raw material melting point)

- Holding time

- Furnace atmosphere (commonly protected by hydrogen or nitrogen to prevent oxidation)

Through precise regulation, powder particles can be fully bonded, increasing the green density to over 95%. The product achieves mechanical properties comparable to forged and cast parts, while retaining the dimensional advantages of precision forming.

Conclusion

The precision manufacturing logic of powder metallurgy is a closed-loop collaboration:

powder production as the foundation, forming for shaping, and sintering for performance enhancement.

Parameter control in each step focuses on precision, uniformity, and densification. This approach not only realizes near-net-shape forming of components and reduces material waste, but also enables mass production of high-precision, high-performance products. Therefore, powder metallurgy has become a core process for high-end manufacturing to reduce costs, improve efficiency, and break through technical bottlenecks.
